This article has been updated for the MUTCD 11th Edition, published December 2023 by the FHWA. The 11th Edition supersedes the 2009 MUTCD and introduces updated requirements and compliance timelines for yield sign applications and placement. States must adopt the 11th Edition by January 18, 2026.
MUTCD Yield Sign Requirements and Compliance Dates
The Manual on Uniform Traffic Control Devices (MUTCD) establishes the standards for yield sign design, application, and placement on roadways under the jurisdiction of the Federal Highway Administration (FHWA). With the publication of the 11th Edition in December 2023, these requirements have been updated and consolidated.
11th Edition Yield Sign Requirements
The 11th Edition of the MUTCD continues and refines the yield sign standards from previous editions. Key provisions include requirements for yield sign design, application criteria, placement standards, and the use of Yield Here to Pedestrians signs. The FHWA published the 11th Edition as a Final Rule on December 19, 2023, and it became effective on January 18, 2024. All states and local agencies must adopt the 11th Edition or have a substantially conforming state supplement by January 18, 2026.
What Changed from the 2009 Edition
Previously under the 2009 Edition, several yield sign provisions carried specific compliance dates inherited from the 2003 and 2000 MUTCD editions. These included:
- January 17, 2011 — Section 2B.09: Changes in YIELD sign application criteria from the 1988 MUTCD to the 2003 MUTCD.
- December 22, 2013 — Section 2B.10: Signs mounted on the back of STOP or YIELD signs should not obscure the shape of the STOP sign, with exception for DO NOT ENTER signs.
- December 22, 2013 — Section 2B.11: Yield Here to Pedestrians signs and Stop Here for Pedestrians signs (R1-5 series).
These compliance dates from the 2009 Edition have now passed. Under the 11th Edition, all of these provisions are incorporated as current standards. Agencies that have not yet implemented these requirements should do so immediately, as these are no longer future compliance items but current mandatory standards.
MUTCD 11th Edition — Section 2B.08: YIELD Sign (R1-2)
Standard: The YIELD (R1-2) sign shall be a downward-pointing equilateral triangle with a wide red border and the legend YIELD in red on a white background.
Support: The YIELD sign assigns right-of-way to traffic on certain approaches to an intersection. Vehicles controlled by a YIELD sign need to slow down or stop when necessary to avoid interfering with conflicting traffic.
Section 2B.09: YIELD Sign Applications
Option: YIELD signs may be used instead of STOP signs if engineering judgment indicates that one or more of the following conditions exist:
- When the ability to see all potentially conflicting traffic is sufficient to allow a road user traveling at the posted speed, the 85th-percentile speed, or the statutory speed to pass through the intersection or to stop in a reasonably safe manner.
- If controlling a merge-type movement on the entering roadway where acceleration geometry and/or sight distance is not adequate for merging traffic operation.
- The second crossroad of a divided highway, where the median width at the intersection is 9 m (30 ft) or greater. In this case, a STOP sign may be installed at the entrance to the first roadway of a divided highway, and a YIELD sign may be installed at the entrance to the second roadway.
- An intersection where a special problem exists and where engineering judgment indicates the problem to be susceptible to correction by the use of the YIELD sign.
Standard: A YIELD (R1-2) sign shall be used to assign right-of-way at the entrance to a roundabout intersection.
Section 2B.10: YIELD Sign Placement
Standard: The YIELD sign shall be installed on the right side of the approach to which it applies. YIELD signs shall be placed on both the left and right sides of approaches to roundabout intersections with more than one lane on the signed approach where raised splitter islands are available on the left side of the approach.
When the YIELD sign is installed at this required location and the sign visibility is restricted, a Yield Ahead sign (see Section 2C.29) shall be installed in advance of the YIELD sign. The YIELD sign shall be located as close as practical to the intersection it regulates, while optimizing its visibility to the road user it is intended to regulate.
YIELD signs and STOP signs shall not be mounted on the same post.
Guidance: Other than a DO NOT ENTER sign, no sign should be mounted back-to-back with a YIELD sign in a manner that obscures the shape of the YIELD sign. Yield lines, when used to supplement a YIELD sign, should be located at a point where the road user should yield (see Section 3B.16).
Where two roads intersect at an acute angle, the YIELD sign should be positioned at an angle, or shielded, so that the legend is out of view of traffic to which it does not apply. Except at roundabout intersections, where there is a marked crosswalk at the intersection, the YIELD sign should be installed in advance of the crosswalk line nearest to the approaching traffic.
At a roundabout intersection, to prevent circulating vehicles from yielding unnecessarily, the face of the YIELD sign should not be visible from the circulatory roadway.
Section 2B.11: Yield Here To Pedestrians Signs (R1-5, R1-5a)
Standard: If yield lines are used in advance of an unsignalized marked midblock crosswalk, Yield Here To Pedestrians (R1-5 or R1-5a) signs shall be placed 6.1 to 15 m (20 to 50 ft) in advance of the nearest crosswalk line (see Section 3B.16). The 11th Edition continues to emphasize the importance of these signs at unsignalized crosswalks for pedestrian safety.
Key 11th Edition Compliance Timeline
The FHWA’s 11th Edition establishes a new compliance framework. Rather than carrying forward the granular compliance dates from the 2009 Edition (most of which have already passed), the 11th Edition requires full adoption by January 18, 2026. Agencies should review their current yield sign inventory against the 11th Edition standards and plan any necessary updates within this timeframe.
For agencies that have been maintaining compliance with the 2009 MUTCD, many yield sign provisions remain substantively similar. However, the 11th Edition includes updated language, refined guidance on roundabout yield sign placement, and enhanced pedestrian safety provisions that should be reviewed carefully.
